sort-comparisons.c File Reference

#include <stdio.h>
#include <stdlib.h>
#include <time.h>

Include dependency graph for sort-comparisons.c:

Data Structures
struct	sorts

Macros
#define	numAlgs   5

Typedefs
typedef struct sorts	sorts

Functions
void	selectionSort (int a[], int n)
void	insertionSort (int a[], int n)
int	impPartition (int a[], int size, int left, int right)
void	hybridQuicksortHelper (int a[], int size, int left, int right)
void	hybridQuicksort (int a[], int n)
void	merge (int aInit[], int aRes[], int aInitLength, int start1, int start2, int end2)
void	mergeSort (int initArr[], int n)
void	percDown (int array[], int hole, int size)
void	heapSort (int a[], int n)
char *	checkAscValues (int a[], int n)
char *	checkAscending (int a[], int n)
int	main ()

Detailed Description

---

Remarks

program times several sorting algorithms on data sets of various sizes *

this version includes code for straight selection insertion sorts * stubbs are provided for other sorting algoritms, including * hybrid quicksort, merge sort and heap sort *

Author

Henry M. Walker *

Remarks

Assignment Comparison of Sorting Algorithms *

Date

August 15, 2022 *

Remarks

References *

Dynamic Programming: Anany Levitin, "The Design and * and Analysis of Algorithms", Second Edition, * Sections 3.1 (Selectino Sort), 4.1 (Insertion Sort), * 5.1 (Mergesort), 5.2 (Quicksort), 6.4 (Heapsort) *

People participating with Problem/Progra Discussions: * Marcia Watts *

Macro Definition Documentation

numAlgs

#define numAlgs   5

Typedef Documentation

sorts

typedef struct sorts sorts

---

structure to identify both the name of a sorting algorithm and * a pointer to the function that performs the sort * the main function utilizes this struct to define an array of * the sorting algorithms to be timed by this program. *

Function Documentation

checkAscending()

char* checkAscending	(	int	a[],
		int	n
	)

---

check all array elements are in non-descending order *

Parameters

a	the array to be sorted *
n	the size of the array * returns "ok" if array elements in non-descending order; "NO" otherwise *

Here is the caller graph for this function:

checkAscValues()

char* checkAscValues	(	int	a[],
		int	n
	)

---

check all array elements have values 0, 2, 4, . . ., 2(n-1) *

Parameters

a	the array to be sorted *
n	the size of the array * returns "ok" if array contains required elements; "NO" if not *

Here is the caller graph for this function:

heapSort()

void heapSort	(	int	a[],
		int	n
	)

---

heap sort, main function *

Parameters

a	the array to be sorted *
n	the size of the array *

Postcondition

the first n elements of a are sorted in non-descending order *

Here is the call graph for this function:

Here is the caller graph for this function:

hybridQuicksort()

void hybridQuicksort	(	int	a[],
		int	n
	)

---

hybrid quicksort, main function * algoithmic elements * random pivot used in partition function * insertion used for small array segments *

Parameters

a	the array to be sorted *
n	the size of the array *

Postcondition

the first n elements of a are sorted in non-descending order *

Here is the call graph for this function:

Here is the caller graph for this function:

hybridQuicksortHelper()

void hybridQuicksortHelper	(	int	a[],
		int	size,
		int	left,
		int	right
	)

---

Quicksort helper function * algoithmic elements * quicksort used when array segments > variable breakQuicksortToInsertion * insertion sort used for small array segments *

Parameters

a	the array to be processed *
size	the size of the array *
left	the lower index for items to be processed *
right	the upper index for items to be processed *

Postcondition

sorts elements of a between left and right *

Here is the caller graph for this function:

impPartition()

int impPartition	(	int	a[],
		int	size,
		int	left,
		int	right
	)

---

Improved Partition function * uses a[left] as pivot value in processing * algoithmic elements * random pivot utilized * swaps only when required by finding misplaced large and small elements *

Parameters

a	the array to be processed *
size	the size of the array *
left	the lower index for items to be processed *
right	the upper index for items to be processed *

Postcondition

elements of a are rearranged, so that * items between left and index mid are <= a[mid] * items between dex mid and right are >= a[mid] *

Returns

mid *

insertionSort()

void insertionSort	(	int	a[],
		int	n
	)

---

insertion sort *

Parameters

a	the array to be sorted *
n	the size of the array *

Postcondition

the first n elements of a are sorted in non-descending order *

Here is the caller graph for this function:

main()

int main

(

)

---

driver program for testing and timing sorting algorithms *

Here is the call graph for this function:

merge()

void merge	(	int	aInit[],
		int	aRes[],
		int	aInitLength,
		int	start1,
		int	start2,
		int	end2
	)

---

merge sort helper function *

Parameters

aInit	source array for merging *
aRes	target array for merging *
aInitLength	the size of the array segment to be merged *
start1	the first index of the first array segment to be merged *
start2	the first index of the second array segment to be merged *
end2	the last index of the second array segment to be merged *

Postcondition

elements aInit[start1]..aInit[start1+mergeSize] merged with * aInit[start2]..Init[end2] * with the result placed in aRes * Note: it may be that start2 >= aInit.length, in which case, only the * valid part of aInit[start1] is copied *

mergeSort()

void mergeSort	(	int	initArr[],
		int	n
	)

---

merge sort helper function *

Parameters

initArr	the array to be sorted *
n	the size of the array *

Postcondition

the first n elements of a are sorted in non-descending order *

Here is the caller graph for this function:

percDown()

void percDown	(	int	array[],
		int	hole,
		int	size
	)

---

percDown function *

Parameters

array	the array to be made into a heap, starting at hold *
hole	base of subtree for start of processing *
size	the size of the array *

Precondition

all nodes in left and right subtrees of the hole node are heaps *

Postcondition

all nodes in the tree from the hole node downward form a hea *

Here is the caller graph for this function:

selectionSort()

void selectionSort	(	int	a[],
		int	n
	)

---

straight selection sort *

Parameters

a	the array to be sorted *
n	the size of the array *

Postcondition

the first n elements of a are sorted in non-descending order *

Here is the caller graph for this function:
